JIS G 3525

Nominal
Rope
Diameter

Approx.
Nominal
Length
Mass

Minimum breaking force (kN)

Bright/plated

Bright

Grade E

Grade A

Grade B

Grade T

mm

Kg/m

1320/1620

1620

1770

1910

8

0.220

26.0

30.8

32.8

34.5

10

0.343

40.6

48.1

51.3

53.9

11.2

0.430

51.0

60.3

64.3

67.6

12

0.494

58.5

69.2

73.8

77.7

12.5

0.536

63.5

75.1

80.1

84.3

14

0.672

79.6

94.3

100.0

106.0

16

0.878

104.0

123.0

131.0

138.0

ISO 4344

Nominal
Rope
Diameter

(mm)

Approx.
Nominal
Length
Mass
(kg/m)

Minimum breaking force (kN)

Dual Tensil

Single Tensil

Grade

Grade

Grade

Grade

Grade

Grade

Grade

1180/1770

1320/1620

1370/1770

1570/1770

1570

1620

1770

8.0

0.218

25.7

26.5

28.1

30.8

29.4

30.4

33.2

9.0

0.275

32.5

-

35.6

38.9

37.3

-

42.0

9.5

0.307

36.2

37.3

39.7

43.6

41.5

42.8

46.8

10.0

0.340

40.1

41.3

44.0

48.1

46.0

47.5

51.9

11.0

0.411

48.6

50.0

53.2

58.1

55.7

57.4

62.8

12.0

0.490

57.8

59.5

63.3

69.2

66.2

68.4

74.7

12.7

0.548

64.7

66.6

70.9

77.5

74.2

76.6

83.6

13.0

0.575

67.8

69.8

74.3

81.2

77.7

80.2

87.6

14.0

0.666

78.7

81.0

86.1

94.2

90.2

93.0

102.0

14.3

0.695

82.1

-

-

98.3

-

-

-

15.0

0.765

90.3

-

98.9

108.0

104.0

-

117.0

16.0

0.870

103.0

106.0

113.0

123.0

118.0

122.0

133.0
