FEATURES

• 2WAY ACCESS methods (RF Card, Pin number)
• Durable body using metallic material
• Automatic lock / Re-lock / Double lock functions
• Safe to use the pin number with dummy number
• Multi-registrations for pin-number & electronic key
• Multiple volume control / optional mute
• Emergency power (9V square battery)
• Anti high-voltage / Anti-hacking system
• Home networking of remote controller (CDL-400MC/410MC)
• Edge Design (CDL-410M)

SPECIFICATION

Applicable:           Normal fire door
Thickness            40mm ~ 60mm

Access methods: Pin number: 4~12 digit number combination (Up to 4 pin number)
RF card:               Up to 30 keys
Emergency key:   Can be used under out of battery

Power source:      DC 6V
                             Alkaline AA battery,4pcs(LR6 1.5V AA size)

Emergency:          DC 9V
                             Alkaline battery (Optional)

Wireless devices For safe system:    47.275Mhz

Type of product:   Anti-fireproof type, Temperature sensor type, Key type, Mini Master key door lock

Temperature alarm:  Temperature sensor  60 degree ± 5 degree(Normal test)

Dimension(mm):     80(W)x230(H)x63(D)
