FEATURES

• 3 WAY ACCESS methods (RF Card, Pin number, Mechanical Key)
• Durable body using metallic material for protecting against high temp. and shock
• High Temp. detection, alert and automatic unlocking
• Multi-Layered authentication (Pin number/RF Card)
• Automatic lock / Re-lock / Double lock functions
• Safe to use the pin number with dummy number
• Anti high-voltage / Fireproof / Anti-hacking system
• Connectivity with home network system using remote controller (Option)
• Emergency power (5V Mirco USB)

SPECIFICATION

Applicable:             Normal fire door
                              Thickness 40mm ~ 60mm

Access methods:   Pin number: 4~12 digit number combination(Up to 4 pin number)
                               RF card: Up to 30 card
                               Emergency key: Can be used under out of battery

Power source:         DC 6V
                                Alkaline AA batter y,8pcs(LR6 1.5V AA size)

Emergency:             DC 5V
                                Micro USB 5pin

Wireless devices For safe system:  Option

Type of product:  Fireproof type, Temperature sensor type, Key type, Master key doorlock

Temperature alarm:    Temperature sensor
                                    60 degree ± 5 degree(Normal test)

Dimension(mm):          80(W)x330(H)x71(D)
