FEATURES

• VIVID METALLIC DESIGN

  Clear and waterproof surface with AF(Anti-fingerprinting) application.

• 7 INCH WIDE LCD

  Monitor visitors via 7 inch wide display LCD.

• VIVID DISPLAY AND AUDIO QUALITY

  It leads the world color monitor markets providing undistorted clear view and outstanding quality.

FUNCTION

• 7 inch TFT LCD screen
• PAL/NTSC convertible
• Video talk and door lock release enable (both individual and public entrance)
• Support 2 Monitors, 2 Cameras and 2 Interphones

SPECIFICATION

Power source:        AC 100-240V, 50/60Hz

Mount type:            Wall-mounted type

Mount typeOperating temp:    0℃~40℃

Wiring:                    *Door camera: 4 wires
                               *Interphone: 4 wire

Distance:                 *Door camera: 50m(0.65Ø)
                                *Floor Distributor: 30m(0.65Ø)

Consumption:           Max.10W/standby 3.4W

Dimension(mm):       244(W)×180(H)×18(D)
