FUNCTION

• 2 Door open camera (CDV-70KR3/70AR3 Connectable)
• 3 way access (PW, RF Card, Videophone)
• Enter the password using 10 key
• Illuminance sensor
• Outdoor model
• Housecall and talk
• Motion detection (PIR)
• DRC-40DK: Wall-mounted type
• DRC-41DK: Built-in type

SPECIFICATION

Power source|:             12VD/1A(Adaptor)

Operation Temp:           -10℃(tested up to -40℃) ~ +50℃

Wiring:                          4 wires to a monitor
                                     2 wires to the DOOR 1
                                     3 wires to DOOR 2(non-polarity)

Minimum Illumination:   0.1Lux (up to 300mm)

Lighting:                       Built-in white LED (3 pie) 2 EA

Imaging angle:             110°diagonal

Camera angle adjusting

                                    Ascendant: 12°/ Descendant: 12°

Scanning frequency:   NTSC/PAL

Distance:                    28m(Ø0.5 UTP)

Image Sensor:           Color C-MOS

Dimension(mm):        DRC-40DK: 127(W)×193(H)×54(D)
                                  DRC-41DK: 127(W)×193(H)×63(D)
