FUNCTION

• Motion detection
• Temperature & Humidity detection
• Low power consumption
• ZigBee communication support

SPECIFICATION

Product (Battery):           CR123A 1ea, 3V (Operating Voltage : 2.4~3V)

PIR:                                Distance 5m Angle 120˚

Operating Temp.:           -40ºC ~+125ºC(+/-2ºC)

Humidity:                        0~100%RH(+/-5%)

Operating Time:              1 Year(50 Times/a day)

Protocol:                          IEEE 802.15.4, Zigbee HA 1.2(Compatible)

Dimension(mm):              80(W)x80(H)x60(D)
