product detail
Operating temperature -20oC ... 50oC
Wire section connection: 0.5 - 2.4 sq.mm
Diode parameters:
Reverse peak voltage: 1000V
DC lock voltage: 1000VDC
Rectifier current at 75oC: 1A
Size parameters:
| Chanel Number | 4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 22 | 24 |
| W (mm) | 88 | 88 | 88 | 88 | 88 | 88 | 88 | 88 | 88 | 88 | 88 |
| H (mm) | 51 | 51 | 51 | 51 | 51 | 51 | 51 | 51 | 51 | 51 | 51 |
| L (mm) | |||||||||||
| Module with single diode | 32 | - | - | 53 | - | 73 | - | 95 | 113 | - | 133 |
| Module with common anode diode | - | - | 32 | - | - | - | 53 | - | - | 73 | - |
| Module with common cathode diode | - | - | 32 | - | - | - | 53 | - | - | 73 | - |
| Module with single lights | - | 63 | 73 | - | 113 | - | - | - | - | - | - |
| Module with common anode lamp | - | 38 | - | - | 63 | 73 | - | 90 | - | - | - |
| Module with common cathode diode | - | 38 | - | - | 63 | 73 | - | 90 | - | - | - |
| Test module with AC lamp | - | 40 | - | - | 63 | - | - | - | - | - | - |
