• Feature

- Considering user convenience

•  For the convenience of timer program input and use, we made it for user to operate easily by separating
• digit button & multi-function button.

- Adopting large vacuum fluorescent display

•  By adopting large Vacuum Fluorescent Display, you can verify the operation status to each function as well as
• various text displays at a look.

- Programing using PC

•  You can easily schedule via management program by connecting PC with RS-232C port.

- Various melodies and voices output

•  You can play various melodies and voices by interlocking SD Card mounted to this device and
• PV-6232A, our model.

- Hosting using USB terminal

•  You can download MP3 file from computer to SD Card mounted to the device by connecting USB cable or mount
• USB memory to save the file into internal memory through COPY function.
•  You can save 9999 melodies additionally other than 15 melodies provided initially and for storage capacity,
• please leave 10% of SD Card capacity (up to 32GB supported).

- Key lock

•  Schedule and user setting can be protected.

- BACK-UP power

•  Under the setting of current time, even though AC power turns off, power can be maintained for
• about a week of time with internal Back-Up power. Within the time which Back-Up power is maintained,
• even though AC power is reauthorized, there is no need to re-adjust the time.

- Blackout measurement

•  Separate Memory is used to prevent the data loss from blackout or other instable power.

- Automatic return

•  When entering schedule data not using PC but using the front button, if any button is pushed for 1 minute,
• it is regarded as input cancellation and it returns to normal operation status.
