FEATURES

• EMS (ENERGY MANAGEMENT SYSTEM)

  It is possible to monitor the energy status on a real-time basis.

• ENHANCE CONVENIENCE FUNCTIONS

  Searching for various contents from public facilities and connect.

• CONVENIENCE

  touch-screen with userfriendly GUI application and various convenience functions enabled.

FUNCTION

• 10.1 inch TFT LED display
• Touch-screen with user-friendly GUI application
• DID function
• Security function & Light control
• Energy Management System
• Users can connect remotely, via their smartphones

SPECIFICATION

Power source:             DC14V, 1.8A

Power consumption:   Standby : 560mA, Max.: 1.4A

Mount type:                 Flush-mounted type

Operating temp.:         0°C~40°C

Wiring:                         Guard/Lobby : Common 10 wires+ 5C2V
                                    Coaxial cable(2 Wire) Door Camera: 4 wire

Distance:                     Individual entrance : 50m(0.65Ø)
Guard station :           1km(0.65Ø)
Public entrance :        300m(5C2V)

Dimension(mm):          318(W)×215(H)×18(61)(D)
