20-32 A:
10x38 & BS fuse versions
DIN rail and screw base mounting as standard
Available as 3-pole and 4-pole version, 1-pole and 2-pole versions on request
Handle LK10 and shaft L=180 mm included, suitable for 250 mm deep panel boards
Fuse covers included
Black or yellow/red handle, add Y/R to description
63-630 A:
DIN & BS fuse versions
Four breaking points per phase
Connecting silver rivets have a silver alloy 350 um thick, thus ensuring a long life expectancy and safe use in demanding conditions
Compact size saves space
Modular structure enables position of drive mechanism to be varied, mention when ordering
Available as 1-, 2-, 3- and 4-pole (200-630 A also 6-pole)
Black or yellow/red handle (add Y/R to description)
Auxiliary contacts are easy to install
Fuse covers included, terminal covers as accessory
63-160 A includes handle LK12 and shaft L=220
200-630 A includes handle LK14 and shaft LVK=228
CERTIFICATES
CE RoHS GostR EAC
