FEATURES

• Built-in illumination sensor
• Outdoor model
• Wall-mounted type
• 6 buttons
• House call and talk
• 2 door open(option)

FUNCTION

• Built-in illumination sensor
• Outdoor model
• Wall-mounted type
• 6 buttons
• House call and talk
• 2 door open(option)

SPECIFICATION

Power source:          12V(From monitor / adaptor)

Operation Temp:      -40℃~+40℃

Wiring:                      4 wires

Minimum:                 0.1Lux(up to 300mm)

Lighting:                    Built-in white LED

Camera view angle:

                                  Horizontal 68° Vertical 55°

Camera angle adjusting

                                  Ascendant: 10°/ Descendant: 10°

Scanning frequency:NTSC/PAL

Distance:                  28m(0.5Ø) 50m(0.65Ø)

Image Sensor:         C-MOS(1/4 inch)

Dimension(mm):       58.7(W)×164(H)×42(D)
